Name: BTT SD Cloud V1.0 Cloud Wireless Transmission Module
SKU: OR06152-DB2
Price: 15000 IQD
Availability: InStock

BTT SD Cloud V1.0 Cloud Wireless Transmission Module

موديل يتيح إمكانية نقل البيانات من الحاسبة الى الطابعة الثلاثية الابعاد بدون كيبل Wireless.

In stock

Module parameters：

1) The module adopts ESP-12S, which is based on ESP8266’s low-power UART-WIFI chip module;

2) The main frequency supports 80MHz and 160MHz;

3) Spectrum range: 2412-2484MHZ;

4) Logic voltage: DC 3.3v;

5) USB input voltage: DC 5V;

6) Size: SD-24mm *58.3mm; TF – 24 mm * 45.5 mm;

7) Transmission file name format requirements: only support the file name consisting of ASCII code;

8) TF card memory: 128M.

Scope of application:

Any SD card interface that communicates via SPI can be plugged in and used directly. Such as:

BIGTREETECH SKR series motherboard、GTR motherboard、BIGTREETECH TFT24 V1.1、BIGTREETECH TFT35 V3.0、BIGTREETECH TFT35-E3 V3.0 and so on；

Notice : all SD card interfaces that communicate via SDIO mode cannot be used; For example: BIGTREETECH TFT35 V2.0!!

Reviews

There are no reviews yet.

Only logged in customers who have purchased this product may leave a review.

SKU: OR06152-DB2 Category: Motherboards Tag: BTT
